UP-EDGE-APL03C2F-A10-0216
Brand: AAEON [An ASUS Co.]
Categories: UP
Processor Options: Powered by Intel’s Pentium® N4200, Celeron® N3350, or Atom E3950 processors, the UP 4000 System balances performance and energy efficiency, making it suitable for various computing tasks while consuming less power.
Enhanced Display and Connectivity: It supports dual 4K displays at 30Hz, and comes with Gigabit LAN, HDMI, and three USB 3.2 Gen 1 Type-A ports, allowing for high-quality visuals and reliable data transfer in multimedia and data-centric applications.
Reliable and Secure: With onboard LPDDR4 memory (up to 8GB), eMMC storage (up to 64GB), and TPM 2.0 for hardware-based security, the UP 4000 ensures stable performance and enhanced security for IoT and industrial applications.
UP-EDGE-APL03C2F-A10-0216,UP-EDGE-APL03C2F-A10-0216,UP-EDGE-APL03C2F-A10-0216,UP-EDGE-APL03C2F-A10-0216,UP-EDGE-APL03C2F-A10-0216,UP 4000 EDGE,Industrial Box PC,Industrial Box PC,UP,UP Gateway System,NULL,Industrial MotherboardFeatures
| Product Code | UP-EDGE-APL03C2F-A10-0216 |
| Fanless | Processor [CPU] |
| Intel® Celeron® N3350 2 Core 1.10 / 2.40 GHz | BM : 1107 | Processor [CPU] Family |
| Intel® Celeron® | RAM [System Memory] |
| 2 GB | SSD / HDD / mSATA / M.2 |
| 16 GB | LAN/Ethernet |
| RTL8111H | USB 3.0 |
| x 1 | USB 3.2 |
| x 3 | USB 2.0 |
| HDMI 1.4b | LVDS |
| Line out x 1Mic in x 1 | Expansion Slot |
| 12V @ 1.25A (15Watt) | Mounting Type |
| VESA MOUNTING | Supply voltage |
| 12V DC-in @5A | Operating temperature |
| 32°F ~ 140°F (0°C ~ 60°C) with air flow 0.5m/s | External Dimensions (mm) |
| 0.64lb (290g) | Body Material |
| CE/FCC Class A, RoHS Compliant, REACH | Supported Operating Systems |
