TF-HSB-800I-A10-VG
Brand: AAEON [An ASUS Co.]
Categories: Half Size CPU Card
AAEON HSB-800i is designed to target the industrial control and automation market. The HSB-800 product is based on AMD® LX800 processor performance, providing lower power consumption and faster heat dissipation.
HSB-800 supports up to 128MB of internal DDR400 system memory with AMD®LX800+CS5536 chipset. The VGA controller for the display function, supporting CRT and LVDS simultaneous display, is integrated into the AMD® LX 800 processor.
Additionally, the HSB-800 supports up to 24-bit LVDS/TTL LCD with integrated 2D/3D graphics accelerator to increase graphics performance.
AAEON has SBC on top of each other in half size, down to a more economical level. Although the economical version of the HSB-800 also offers the ideal balance of price and performance.
Features
| Product Code | TF-HSB-800I-A10-VG |
| Form Factor | Half Size CPU Card |
| Card Size (mm) | 185 x 122 |
| Cooling | Fanless |
| Processor [CPU] | AMD® GEODE™ LX800 2 Core 0.50 GHz | BM : 252 |
| Processor [CPU] Family | AMD® |
| RAM [System Memory] | Onboard |
| SSD/HDD/mSATA/M.2 | CFast x 1 |
| LAN/Ethernet | GbE x 1 |
| USB 2.0 | x 4 |
| RS 232 Serial Port | x 3 |
| RS 232/422/485 Serial Port | x 1 |
| Video Output | VGA x 1 + LVDS x 1 |
| Expansion Slot | PC/104 x 1 |
| Supply Voltage | DC 12 V AT/ATX |
| Operating temperature | 0°C ~ 60°C |
| Certificates | CE |
