SRG-IMX8P-A11-0216
Brand: AAEON [An ASUS Co.]
Categories: IoT Gateway
Standard RISC Gateway with ARM® i.MX8M Plus Quad-Core Cortex-A53 1.6GHz Processor
Features
NXP i.MX8M Plus Quad Cortex-A53 1.60 GHz RISC Processor
onboard LPDDR4 2 GB / eMMC 16 GB (Optional 4 GB RAM / eMMC 32 GB)
HDMI 2.0a
GbE x 2
USB 3.0 x 2, Full Size mPCIe x 2, CAN-FD x 2 CH, Micro SD Card Slot x 1, RTC, TPM 2.0
Wide DC Input 9~36V
Wide Temperature -20°C ~ 70°C
UL61010 certified; PLC and heavy industry IEC61000-6-2, IEC61000-6-4, IEC61131-2 approved
Pre-install Linux Debian 11; Support Android 13, Win 10 IoT, Yocto
Supports Modbus/ MQTT Library/ OPCUA/ Security boot/ GUI/ Machine learning eIQ (on request)
Features
| Product Code | SRG-IMX8P-A11-0216 |
| Cooling | Fanless |
| Processor [CPU] | ARM® NXP i.MX8M Plus, Quad-Core Cortex-A53, 1.60 GHz Processor |
| Processor [CPU] family | ARM |
| RAM [System Memory] | 2 GB |
| SSD/HDD/mSATA/M.2 | 16 GB eMMC | MicroSD x 1 |
| LAN/Ethernet | GbE x 2 |
| USB 3.0 | x 2 |
| CAN-FD | x 2 |
| RS 485 Serial Port | x 2 |
| Video Output | HDMI x 1 |
| Expansion Slot | Mini-PCIe x 2 | SIM x 1 |
| 4G - LTE | SIM (Opsiyonel) |
| Mounting Type | Wallmount | Din Rail | optional |
| Supply voltage | DC 9V - 36V |
| Operating temperature | -20°C / 70°C |
| External Dimensions (mm) | 140.76 x 98.2 x 48 |
| Body Material | Aluminum |
| Certificates | CE | FCC |
