SI-304-225
Brand: IBASE
Categories: Signage Player
The SI-304 is a digital signage player with four (4) HDMI outputs supporting 4K resolution of 4096 x 2160 per display channel. The SI-304 is not only ideal for 2×2 video walls, it is also suitable for conveying dynamic information and targeted promotions on electronic displays in banks, airports and shopping malls, as well as on menu boards in restaurants.
Powered by the SI-304 2nd generation AMD® R Series Embedded processing unit (APU) accelerated AMD® Radeon™ HD 9000 graphics card, it delivers outstanding graphics performance and power efficiency. 2x for WiFi, Bluetooth or 4G/LTE functions
The SI-304 is designed with a separate vent to keep contaminants out and increase system stability. It also supports AMD® Eyefinity™ Technology, which allows users to easily configure multi-display configuration. 263mm'
Features
| Product Code | SI-304-225 |
| Processor [CPU] | AMD® RX-225FB 2 Core 2.20 / 3.00 GHz | BM : 890 |
| Processor [CPU] Family | AMD® |
| RAM [System Memory] | [Max 32 GB] |
| SSD/HDD/mSATA/M.2 | 64 GB mSATA |
| LAN/Ethernet | GbE x 2 |
| USB 3.0 | x 2 |
| USB 2.0 | x 1 |
| RS 232 Serial Port | x 1 |
| Video Output | HDMI x 3 |
| Expansion Slot | Full Size Mini-PCIe |
| Mounting Type | wall mount |
| Supply Voltage | DC 12 V |
| Operating temperature | 0°C ~ 45°C |
| External Dimensions (mm) | 269 x 193 x 31.5 |
| Chassie Material | Aluminum |
| Certificates | CE | FCC |
| Supported Operating Systems | Windows 10 | Windows 8 | Windows 7 | Linux Ubuntu 22.04 | Licence Price is excluded. |
