SA-112-NQC
Brand: IBASE
Categories: ARM-based signage player
SA-112-N is a rugged Fanless system specifically designed for outdoor digital signage application. Featuring a compact 11.7 x 10.4 x 3.2cm aluminum body, this player supports the Freescale IMX6Q Automotive CPU operating over a wide temperature range (-40°C to 75°C) and is shock/vibration resistant. SA-112-N provides various wireless communication module Expansion for GPS, Bluetooth, wireless WAN 2.5G GPRS or 3.5G CDMA/HSDPA to ensure fast and effective information exchange. With a product lifespan of up to five years, the device comes with autoplay functionality and supports HDMI and VGA display outputs.
Features
| Product Code | SA-112-NQC |
| Processor [CPU] | IMX6QC 1 GHz |
| Processor [CPU] Family | ARM |
| RAM [System Memory] | 6 GB Onboard |
| SSD/HDD/mSATA/M.2 | 8 GB eMMC |
| LAN/Ethernet | GbE x 1 |
| USB 2.0 | x 2 |
| RS 232 Serial Port | x 1 |
| Video Output | HDMI x 1 + VGA x 1 |
| Expansion Slot | Full Size Mini-PCIe | M.2 B Key x 1 | M.2 E Key x 1 |
| Mounting Type | Standard system bracket |
| Supply voltage | DC 5V |
| Operating temperature | -40°C / 75°C |
| External Dimensions (mm) | 117 x 104.5 x 32.2 |
| Weight (kg) | 0,5 |
| Body Material | Aluminum |
| Certificates | CE |
