RT-680T-Q470E-A10-0001
Brand: AAEON [An ASUS Co.]
Categories: Workstation
RT-680T-Q470E-A10-0001 offers high-performance industrial computers with 10th Generation Intel® Core™ processors.
Provides expandable hardware support with PCIe 3.0 and M.2 slots.
High-speed data transfer is possible with USB 3.2 Gen 2 x 4.
Different display configurations are supported with HDMI, VGA and DisplayPort outputs.
It provides reliable performance in the temperature range of 0°C to 45°C.
Features
| Product Code | RT-680T-Q470E-A10-0001 |
| Cooling | Fan |
| Processor [CPU] | Intel® Xeon® |Core™ i7 | i5 | i3 | Pentium® | Celeron® |
| Processor [CPU] Family | Konfigüre edilebilir Intel® Xeon® |Core™ i7 | i5 | i3 | Pentium® | Celeron® |
| RAM [System Memory] | DDR4 [Max 128 GB] |
| SSD/HDD/mSATA/M.2 | SATA3 x 6 | RAID | M.2 M Key x 1 |
| LAN/Ethernet | 2.5 GbE x 1 |
| USB 3.2 | USB 3.2 Gen2 1x 4 |
| USB 2.0 | x 2 |
| RS 232/422/485 Serial Port | x 2 |
| Video Output | HDMI x 1 + VGA x 1 + DP x 1 |
| Expansion Slot | PCIe 3.0 x 4 | PCIx2 | M.2 x 1 | M.2 E Key x 1 | PCIe x 1 |
| TPM | TPM 2.0 |
| Mounting Type | stand |
| Supply Voltage | ATX |
| Working temperature | 0°C ~ 45°C |
| External Dimensions (mm) | 198 x 465 x 425 |
| Body Material | Aluminum |
| Certificates | CE |
| Supported Operating Systems | Windows®10 | Windows®8 | Windows®7 | Linux Ubuntu 22.04 | Operating system sold separately from license. |
