OMNI-310DHTT-KIT-A2-1011
Brand: AAEON [An ASUS Co.]
Categories: OMNI Panel Kits
OMNI Series Touch Panel Kit modules-
Features
| Product Code | OMNI-310DHTT-KIT-A2-1011 |
| Screen size | 10.4" TFT LCD |
| Resolution | 800 x 600 |
| Screen Format | 4 | 3 |
| Brightness | 230 cd/m² |
| Contrast | 1000 | 1 |
| Viewing Angle | 120°(H ) / 100°(V) |
| Touch Type | Projected Kapasitif [P-CAP] |
| Backlight Life (Min. Hours) | 50.000 |
| RAM [System Memory] | NULL |
| LVDS | x 1 |
| Operating temperature | -10°C / 55°C |
| External Dimensions (mm) | 280 x 239 x 59 |
| Weight (kg) | 2 |
| Body Material | Aluminum |
| IP Protection Class | IP65 Compatible Aluminum Front Frame |
| Certificates | CE | FCC |
