OMNI Series Touch Panel Kit modules-
Product Code | OMNI-310DHTT-KIT-A2-1011 |
Screen size | 10.4" TFT LCD |
Resolution | 800 x 600 |
Screen Format | 4 | 3 |
Brightness | 230 cd/m² |
Contrast | 1000 | 1 |
Viewing Angle | 120°(H ) / 100°(V) |
Touch Type | Projected Kapasitif [P-CAP] |
Backlight Life (Min. Hours) | 50.000 |
RAM [System Memory] | NULL |
LVDS | x 1 |
Operating temperature | -10°C / 55°C |
External Dimensions (mm) | 280 x 239 x 59 |
Weight (kg) | 2 |
Body Material | Aluminum |
IP Protection Class | IP65 Compatible Aluminum Front Frame |
Certificates | CE | FCC |
