MRD286-I50
Brand: IBASE
Categories: EN50155 Rail System Panel PC
EN50155 Certified Intel® Atom™ x7-E3950 / Pentium® N4200 Processor All-in-One 28.6-inch Bar Panel PC ● Intel® Atom™ x7-E3950 / Pentium® N4200 Processor ● Sunlight readable 1000nits bar panel ● Automatic dimming function ● IP65 front panel waterproof protection ● Anti-scatter front glass
MRD-286 is an all-in-one 28.6-inch stick type panel PC with EN50155 certification. Integrates an Intel® Pentium® Processor N4200 or Intel® Atom x7-E3950 Processor powered by 24VDC or 110VDC power input. With ultra-wide TFT active matrix LCD display, the system
Features
| Product Code | MRD286-I50 |
| Screen size | 28.6" TFT LCD |
| Resolution | 1920 x 540 |
| Brightness | 1000 cd/m² |
| Viewing Angle | 178°(H ) / 178°(V) |
| Backlight Life (Min. Hours) | 50000 |
| Cooling | Fanless |
| Processor [CPU] | Intel® Atom® x7-E3950 4 Core 1.60 GHz | BM : 2150 |
| Processor [CPU] Family | Intel® Atom® |
| RAM [System Memory] | 4 GB |
| SSD/HDD/mSATA/M.2 | 64 GB mSATA | [Upgradable] |
| LAN/Ethernet | GbE x 1 [M12] |
| USB 2.0 | x 2 [M12] |
| RS 232/422/485 Serial Port | x 1 [[M12]] |
| Expansion Slot | Full Size Mini-PCIe [x1] |
| Mounting Type | Side Mounting |
| Supply Voltage | DC 24 V |
| Operating temperature | -25°C ~ 55°C |
| External Dimensions (mm) | 780 x 278 x 77 |
| Chassie Material | Aluminum |
| Certificates | CE | FCC | EN50155 | LVD |
| Supported Operating Systems | Windows 10 | Linux | Licence Price is excluded. |
