IPC4-RT-AT17X-8128
Brand: IPC4 by ICC
Categories:
durable industrial tablet PC equipped with the high-performance MediaTek MT6789 Octa-Core processor.
It provides clear viewing outdoors with its 10.1" TFT screen (1920x1200 resolution, 700 nit brightness).
It offers a smooth and powerful Android experience with 8GB LPDDR4 RAM.
128GB eMMC internal storage, expandable with Micro SD card support up to 512GB.
It offers fast wireless connection with Wi-Fi 802.11 a/b/g/n/ac dual band (2.4G + 5.8G).
It provides quality photo and video shooting with its front 5 MP and rear 13 MP cameras.
It offers up to 9 hours of usage time with a removable 10000 mAh battery.
It offers up-to-date, safe and compatible use with the Android 14 operating system.
Bluetooth 5.1 BLE provides effective wireless data transfer with low power consumption.
It is compatible with ISO/IEC 14443A/B/15693/18092/Mifare protocols with NFC support and offers a reading distance of 0–4 cm.
It offers precise location tracking with GPS, GLONASS, BEIDOU, Galileo, QZSS and SBAS support.
It provides mobile network access thanks to dual Nano SIM card support.
The Zebra SE4710 is suitable for warehouse and field applications with an optional 2D barcode reader.
It offers USB Type-C (supports 18W fast charging) and USB 2.0 ports.
Provides dock and accessory compatibility with 12PIN Pogo Pin connection.
It offers rich sensor support with hardware such as G-sensor, gyroscope, compass and light sensor.
With its durable ABS+PC body, IP65 protection and MIL-STD-810H certification, it can be used safely in harsh environments.
The touch screen is a G+G panel with 10-finger support and is scratch resistant with 7H hardness.
Built-in dual speakers (8Ω/1W x2) provide clear and powerful sound output.
Standard accessories: 18W fast charging adapter, Type-C cable, hand strap. Optional accessories: DC87R dock, VHM87R car mount kit, removable battery.
Thanks to the high-resolution screens of the IPC4 Rugged Tablets, technical data, drawings and applications are displayed clearly and in detail.
With its durable construction, long-lasting battery and comprehensive connectivity options, the IPC4 AT17X is the reliable solution for industrial uses.
Features
| Product Code | IPC4-RT-AT17X-8128 |
| Screen size | 10.1" TFT LCD |
| Resolution | 1920 x 1200 |
| Screen Format | 16 | 10 |
| Brightness | 700 cd/m² |
| Touch Type | 10-point capacitive [G+G, 7H hardness] |
| Embedded GPU | ARM Mali-G57 MC2 |
| Cooling | Without Fan |
| Processor [CPU] | MediaTek MT6789 Octa-Core |
| Processor [CPU] Family | MediaTek® |
| RAM [System Memory] | 8 GB |
| SSD/HDD/mSATA/M.2 | 128 GB eMMC |
| LAN/Ethernet | RJ45 x 1 (10/100Mbps) Optional |
| USB 2.0 | x1 |
| USB Type-C | x 1 (18W Fast Charging PE+2.0) |
| RS 232 Serial Port | Optional |
| Video Output | x 0 |
| POGO | 12PIN Pogo Pin x 1 |
| Audio Output | Built in 8Ω/1W Waterproof Speaker x 2 |
| Expansion Slot | Micro SD x 1 (supports 512GB) |
| Wireless | 802.11 a/b/g/n/ac |
| Bluetooth | BT5.1 (BLE) |
| Front camera | 5MP |
| Rear Camera | 13 MP |
| 4G - LTE | It comes with standard hardware. It will be delivered with an IMEI registration to BTK. IMEI registration is included in the price. |
| GPS | (+) |
| G Sensor | (+) |
| 2D/QR Code Reader | Optional Zebra SE4710 |
| NFC | Optional |
| Gyro-Sensor | (+) |
| Battery | 10000mAh / 3.8V, removable |
| Battery Usage Time | 9 hours (default 50% volume, WiFi on, 200 nits, 1080P video) |
| Docking + In-Vehicle Mounting | (Optional) DC87R, VHM87R |
| SHIMMER | x 2 (Nano SIM) |
| Light Sensor | (+) |
| E-compass | (+) |
| Supply Voltage | DC 9V |
| Working temperature | -20°C ~ 60°C |
| External Dimensions (mm) | 274.9 x 188.7 x 23.1 |
| Weight (kg) | 1140g |
| Body Material | ABS+PC |
| IP Protection Class | IP65 |
| Certificates | CE | MIL-STD-810H |
| Supported Operating Systems | Android 14 |
