| Product Code |
INOSP-152-RE |
| Screen size |
15" TFT LCD |
| Resolution |
1024 x 768 |
| Screen Format |
4 | 3 |
| Brightness |
500 cd/m² |
| Contrast |
1000 | 1 |
| Viewing Angle |
160°(H ) / 160°(V)
|
| Touch Type |
Rezistif
|
| Backlight Life (Min. Hours) |
50.000
|
| Cooling |
Fanless
|
| Processor [CPU] |
Intel® Atom™ E3845 4 Core 1.91 GHz BM : 1130
|
| Processor [CPU] Family |
Intel® Atom™
|
| RAM [System Memory] |
4 GB DDR3L Standart | [Max 8 GB]
|
| SSD/HDD/mSATA/M.2 |
2.5" SATA x 1 | [Upgradable]
|
| LAN/Ethernet |
GbE x 1 [M12]
|
| USB 3.0 |
Opsiyonel [M12]
|
| USB 2.0 |
x 1 [M12]
|
| RS 232 Serial Port |
x 1 [M12]
|
| RS 232/422/485 Serial Port |
x 1 [[M12]]
|
| Mounting Type |
VESA 75 | Panel Mount | Stand | Mounting Unit Not Included.
|
| Supply voltage |
DC 10V - 24V
|
| Operating temperature |
0°C / 50°C
|
| External Dimensions (mm) |
425 x 330 x 62.5
|
| Weight (kg) |
4
|
| Body Material |
Aluminum
|
| IP Protection Class |
IP65 Compatible Aluminum Front Frame
|
| Certificates |
CE | FCC | LVD
|
| Supported Operating Systems |
Windows® 10 IoT | Pro | Windows® 8 | Linux | License Not Included in the Price.
|
