GENESYS-APL7-A10-FS01
Brand: AAEON [An ASUS Co.]
Categories: Industrial Box PC
3.5" sub-compact Motherboard System powered by Intel® Pentium® N4200/N3350 Celeron processor
Features
N4200 Intel Pentium/Celeron N3350 Processor
DDR3L 8GB RAM expandable up to 1866MHz SODIMM
VGA Video Output
SATA 6.0Gb/s x 1
USB 3.2 Gen1 x 2, USB 2.0 x 1 COM x 7
mSATA x 1 (full size), MiniCard x 1 (Full size)
12VDC ATX Mode
Features
| Product Code | GENESYS-APL7-A10-FS01 |
| Cooling | Heat Spreader + Fan |
| Processor [CPU] | Intel® Celeron® N3350 2 Core 1.10 / 2.40 GHz | BM : 1107 |
| Processor [CPU] Family | Intel® Celeron® |
| RAM [System Memory] | [Max 8 GB] |
| SSD/HDD/mSATA/M.2 | mSATA x 1 |
| LAN/Ethernet | GbE x 2 |
| USB 3.2 | x 2 |
| USB 2.0 | x 2 |
| RS 232 Serial Port | x 1 x 6 (PIN) |
| Video Output | VGA x 1 |
| Expansion Slot | Full Size Mini-PCIe x 1 | mSATA x 1 |
| Supply Voltage | DC 12 V |
| Operating temperature | 0°C ~ 50°C |
| External Dimensions (mm) | 178 x 134.1 x 50 |
| Chassie Material | Aluminum |
| Certificates | CE | FCC |
| Supported Operating Systems | Windows 10 | Windows 8 | Windows 7 | Linux Ubuntu 22.04 | Licence Price is excluded. |
