Desktop Networking Device with Intel® Atom™ Processor C Series

The FWS-2365 desktop networking appliance is a customizable solution crafted with a wealth of robust functionality, ideal for a variety of applications such as uCPE and SD-WAN.

Along with 5G connectivity support, the system features up to four SFP+ Fiber 10 Gbps Ports and a variety of robust tools and functions to accelerate the deployment of SD security, QoS and other SDN/NFV applications.

The FWS-2365 is equipped with the Intel® Atom™ Processor C Series (formerly Denverton), which supports four to sixteen-core processors and provides the performance needed to enable additional functions.

The system is equipped with key performance acceleration features for Intel processors such as Intel QAT, SR-IOV, AES-NI, Virtualization Technology and DPDK.

The FWS-2365 is designed to deliver faster network speeds and increased throughput with up to four SFP+ Fiber 10 Gbps Ports and six copper Gigabit LAN Ports, with the option to upgrade two of them to SFP.

• DDR4 SODIMM / ECC DIMMs (Dual Core 2 Quad Slot 1 Slot)

FWS-2365 supports LAN Bypass function to ensure uninterrupted connectivity and service.

Features

Desktop Network Device

Intel® Atom™ Processor C Series

DDR4 SODIMM/ECC DIMM (Dual Core 1 Slot, Quad Core 2 Slots)

GbE x 4 (Marvell® Alaska® 88E1543) + GbE x 2 (Intel® Ethernet Controller I210)

2 Double Bypass Support

Mini-PCIe with SIM Slot Support

Internal 2.5" SATA HDD Slot x 1 (Optional)

eMMC, up to 16GB

RJ-45 Console x 1

USB 3.2 Gen1 x 2 (Internal USB 2.0 x 1)
