AAEON's newest desktop networking appliance, the FWS-2273, represents a major step forward in affordable, rugged connectivity and network security. Energy-efficient and user-friendly device that supports a variety of mass storage solutions, wireless gateway and WiFi applications and is ideal for expanded vCPU to deliver 4G LTE.
1 GB Fiber/Copper Ports: One dual fiber Port and four copper SFP GbE LAN Port 2273 FWS-rich I/O capability. Fiber ports provide exceptional speed, while traditional Port FWS-2273 ensures availability of network traffic
Customer-Friendly Housing: Thanks to the FWS-2273's innovative maintenance housing, removal has never been easier with the removal of a single screw. Easily accessible and Mini SIM card covers facilitate system operation and system expansion
Use Versatility: Whether an SMB, home office, or coffee shop needs a wired connection, a customer needs a strong Wi-Fi signal, or a small hotel needs a strong Wi-Fi signal, the FWS-2273 has the ability to stay connected to multiple computers and devices and water.
• N3350 Intel® Celeron® Processor SoC
• 10/100 / 1000BASE-TX x 6 (4 x RJ-45, 2 x SFP Connector)
• Supports up to 2 Double Bypasses
• CF Connector 1 x SATA 6.0 Gb/s 2.5" HDD / SSD Port x 1
• Mini Card Slots (SIM Slot) x 2
• RJ-45 console x 1, USB 3.0 x 2
Product Code | FWS-2273E7-A10-A10-00 |
Cooling | Fanless |
Processor [CPU] | Intel® Celeron® N3350 2 Core 1.10 / 2.40 GHz | BM : 1107 |
Processor [CPU] Family | Intel® Celeron® |
RAM [System Memory] | DDR3L |
SSD/HDD/mSATA/M.2 | 2.5" SATA x 1 | CFast x 1 |
LAN/Ethernet | GbE x 6 |
Video Output | HDMI x 1 |
Expansion Slot | Full Size Mini-PCIe x 1 | PCIe [x1] x 1 | PCIe [x1] x 1 |
Mounting Type | stand |
Supply Voltage | DC V |
Chassie Material | Aluminum |
Certificates | CE | FCC |
Supported Operating Systems | Windows 10 | Windows 8 | Windows 7 | Linux Ubuntu 22.04 | Licence Price is excluded. |
