| Product Code |
ET860-i27-LV |
| Form Factor |
COM Express Type 10
|
| Card Size (mm) |
95 x 95
|
| Processor [CPU] |
Intel® Atom™ E3827 2 Core 1.74 GHz BM : 530
|
| Processor [CPU] Family |
Intel® Atom®
|
| RAM [System Memory] |
[Max 8 GB]
|
| SSD/HDD/mSATA/M.2 |
SATA3 x 2 | MicroSD x 1
|
| LAN/Ethernet |
GbE x 1
|
| USB 3.0 |
x 1
|
| USB 2.0 |
x 8
|
| RS 232 Serial Port |
x 2
|
| RS 232/422/485 Serial Port |
x 1
|
| Digital I/O |
DI x 4 / DO x 4
|
| Video Output |
LVDS x 1
|
| LVDS |
18/24 bit 2CH x 1
|
| Expansion Slot |
PCIe [x1] x 1 | PCIe [x1] x 1
|
| Supply Voltage |
NULL
|
| Certificates |
CE
|
