CSB200-898
Brand: IBASE
Categories: Automation Box PC
The fanless system supports iBASE IB898 3.5" Disk-Size SBC.
Integrated Intel® Atom™ Processor E3825 SoC, 1.33GHz
Features
| Product Code | CSB200-898 |
| Cooling | Fanless |
| Processor [CPU] | Intel® Atom™ E3825 2 Core 1.33 GHz BM : 400 |
| Processor [CPU] Family | Intel® Atom™ |
| RAM [System Memory] | 2 GB DDR3L Standart | [Max 8 GB] |
| SSD/HDD/mSATA/M.2 | 2.5" SATA 320 GB |
| LAN/Ethernet | GbE x 1 |
| USB 3.0 | x 1 |
| USB 2.0 | x 3 |
| RS 232/422/485 Serial Port | x 2 |
| Video Output | VGA x 1 + DP x 1 |
| Wireless | 1 x Antenna hole |
| Mounting Type | stand |
| Supply voltage | DC 12V |
| Operating temperature | -30°C / 60°C |
| External Dimensions (mm) | 172 x 111.6 x 52 |
| Weight (kg) | 6,1 |
| Body Material | Aluminum |
| Certificates | CE |
| Supported Operating Systems | Windows® 10 IoT | Pro | Windows® 8 | Windows® 7 | Linux Ubuntu 22.04 | License Not Included in the Price. |
