8th/9th High Computing Power AI Edge Server with 2nd Generation Intel® Processor and NVIDIA®A2
BOXER-8332AI is designed to bring the powerful performance of 8th and 9th Generation Intel® Core™ processors, also known as Coffee Lake/Coffee Lake Refresh, to advanced applications including AI Edge Server.
Its system supports processors up to 71 watts and provides constant high performance at temperatures between -20 and 60 degrees with its innovative thermal structure.
The system also supports up to 128 gigabytes of memory for crash-free performance.
BOXER-8332AI comes equipped with NVIDIA® A2 by default, but can also support a wide range of non-fan-cooled GPUs.
Two Mini Card slots, M.2 and PCIe [x4] provide greater scalability options.
The system's input/output capabilities leverage six USB 3.2 Gen1 Ports, four COM Ports, three Gigabit Ethernet Ports, and Optional 8-bit DIO functionality, enabling seamless connectivity with a variety of cameras, sensors, and controllers.
The system is designed with compact spaces in mind; It provides seamless integration into machine cabs and facilitates proximity to where performance is required.
High Computing Power
Internal NVIDIA®A2 x1
Intel Coffee Lake-S LGA 1151 Desktop Processor
HDMI x2 for Dual Display
Support C246 PCH
PCIe x4 support
Single Power Input (for both System and one Graphics Card)
Product Code | BOXER-8332AI-CFL-A2-1010 |
AI Accelerator | GPU | Dahili NVIDIA®A2 x1 |
Cooling | Fanless |
Processor [CPU] | Intel® Xeon® E-2124G | Intel® Core™ i7-9700TE | Intel® Core™ i7-8700T | Intel® Core™ i5-8500T | Intel® Core™ i3-8100T | Intel® Pentium® G5400T | Intel® Celeron® G4900T | Intel® Xeon® E-2278GEL |
Processor [CPU] Family | Intel® Core™ Intel® Xeon |
RAM [System Memory] | DDR4 SO-DIMM x 4 | [Max 128 GB] |
SSD/HDD/mSATA/M.2 | mSATA x 1 | M.2 NVME x 1 | 2.5" SATA x 2 |
LAN/Ethernet | GbE x 3 |
USB 3.2 | x 2 |
RS 232/422/485 Serial Port | x 4 |
Video Output | HDMI x 2DVI-I x 1 |
Expansion Slot | Full Size Mini-PCIe x 1 | M.2 M Key x 1 | PCIe [x4] x1 | PCIe [x4] x1 |
Mounting Type | wall mount |
Supply voltage | DC 12V - 24V |
Operating temperature | 0°C / 40°C |
External Dimensions (mm) | 220 x 150 x 280 |
Weight (kg) | 8 |
Body Material | Aluminum |
Certificates | CE | FCC |
Supported Operating Systems | Windows® 10 IoT | Pro | Linux Ubuntu 20.04 | License Not Included in the Price. |
