SI-626 is a digital signage system based on 6th and 7th Generation Intel® Core™ mobile processors and powered by an AMD® Radeon™ E8860 graphics GPU that delivers incredible ultra-high-definition multimedia using the advanced Graphics Core Next (GCN) architecture. Play on six HDMI displays.
To produce a high-performance digital signage player, the SI-626 combines the processing power of the Intel® Core™ i7-7820EQ with the superior graphics capabilities of the AMD® Radeon E8860. The SI-626 is very thin, less than 30mm thick, yet uses components from IBASE
IBASE iCONTROL intelligent energy-saving green technology and Observer remote monitoring technology on SI-626, automatic power planning, power outage detection to reduce outage time, restore to default status in case of system crash
The SI-626 enables ultra-high-definition multimedia playback on multiple screens to capture and hold audience attention like never before in public venues such as large retail stores, shopping malls, airports and train stations.
Product Code | SI-626 |
Processor [CPU] | Intel® Core™ i7-7820EQ 2 Core 2.80 GHz | BM : 7080 |
Processor [CPU] Family | Intel® Core™ i7 7. Gen |
RAM [System Memory] | [Max 32 GB] |
SSD/HDD/mSATA/M.2 | 2.5" SATA 128 GB |
LAN/Ethernet | GbE x 2 |
USB 3.0 | x 4 |
RS 232 Serial Port | x 2 |
Video Output | HDMI x 6 |
Expansion Slot | M.2 E Key x 1 |
Mounting Type | Standard system bracket |
Supply Voltage | DC 12 V |
Working temperature | 0°C ~ 45°C |
External Dimensions (mm) | 290 x 222 x 29.9 |
Body Material | Aluminum |
Certificates | CE | FCC |
Supported Operating Systems | Windows®10 | Linux | Operating system sold separately from license. |
