Based on the 4th Generation Intel® Core™ processor, the SI-60E-6H super high 8K video wall player is specifically built for multi-screen video wall display applications. It supports 6 displays (HDMI 1.4) with independent audio output, and features IBASE's Multi-Display Matrix Technology for flexible VW configuration and resolution adjustment, hardware EDID emulation and frame adjustment. This aesthetically designed player delivers excellent 3D graphics performance with resolutions up to 5760 x 2160. SI-60E-6H also features IBASE's iSMART technology, which features on/off scheduling, power resume function, low temperature protector and intelligent OS recovery to reduce maintenance costs. , enhances system stability and ensures long-term reliability.
Product Code | SI-60E-6H |
Processor [CPU] | Intel® Core™ i7-4770S 4 Core 3.10 GHz | BM : 9345 |
Processor [CPU] Family | Intel® Core™ i7 4. Gen |
RAM [System Memory] | 16 GB Standart |
SSD/HDD/mSATA/M.2 | 2.5" SATA 128 GB |
LAN/Ethernet | GbE x 2 |
USB 3.0 | x 4 |
RS 232 Serial Port | x 1 |
Video Output | HDMI x 6DVI-I x 1 |
Expansion Slot | Full Size Mini PCIe x 1 |
Supply Voltage | AC |
Working temperature | 0°C ~ 45°C |
External Dimensions (mm) | 412 x 310 x 47 |
Body Material | Aluminum |
Certificates | CE | FCC |
Supported Operating Systems | Linux |
