SI-324

Brand: IBASE
Categories: Signage Player

SI-324 is a 4K digital signage player powered by the new AMD® Ryzen™ Embedded V1000 processors that deliver outstanding CPU performance and a noticeable increase in GPU performance over previous solutions. With new integrated AMD® Radeon™ Vega graphics with up to 11 compute units, the SI-324 delivers four independent HDMI 2.0 displays with 4K@60Hz resolution on each display and supports 2x 4K@60 or 4x FHD@60 clear content

SI-324 features IBASE iCONTROL for energy saving, automatic on/off scheduling, remote monitoring, automatic power recovery, low temperature boot protection and intelligent operating system restoration

The SI-324 features flexible video wall configurations suitable for a wide range of applications, including restaurant menu boards and electronic displays in banks, airports and shopping malls to deliver dynamic information and promotions to the target audience.


Features


Product Code SI-324
Processor [CPU] AMD® RYZEN™ V1807B 4 Core 3.40 / 3.80 GHz | BM : 8550
Processor [CPU] Family AMD® RYZEN™
RAM [System Memory] [Max 32 GB]
SSD/HDD/mSATA/M.2 64 GB mSATA
LAN/Ethernet GbE x 2
USB 3.0 x 2
USB 2.0 x 1
Video Output HDMI x 4
Expansion Slot Half Size Mini-PCIe x 1
Mounting Type wall mount
Supply Voltage DC 12 V
Operating temperature 0°C ~ 45°C
External Dimensions (mm) 269 x 193 x 31.5
Chassie Material Aluminum
Certificates CE | FCC
Supported Operating Systems Windows 10 | Linux | Licence Price is excluded.
