PC6012-8G-128G
Brand: PANELMATE
Categories:
PER-P30D-A10-0001 provides high efficiency with its Frame grabber card, DC 5V and DC 12V output power supply module.
Ideal for general purpose applications, this card offers advanced image processing capabilities.
Its compact structure is suitable for use in limited spaces.
Compliant with PCIe Gen 1 [x4], provides high-speed data transmission.
This device is CE and FCC certified and offers reliable performance.
Provides flexible mounting opportunity with DIN rail mounting.
It offers flexible connection opportunities with multiple LAN ports and wide connection options. It has a customizable structure with components such as RAM and storage. It provides fast delivery with ICC's wide stocks.
With PANELMATE Industrial BOOK PC:
Provides reliable performance in machine control and monitoring systems.
It offers flexible solutions in security cameras and building automation systems.
Provides uninterrupted data processing in traffic control and surveillance systems.
It offers an ideal option for impressive billboards.
Features
| Product Code | PC6012-8G-128G |
| Cooling | Without Fan |
| Processor [CPU] | Intel® Celeron® J6412 4 Core 2.00 / 2.60 GHz | BM : 3850 |
| Processor [CPU] Family | Intel® Celeron® |
| RAM [System Memory] | Standart 8 GB [Max 16 GB] |
| SSD/HDD/mSATA/M.2 | 128 GB mSATA | [Yükseltilebilir] |
| LAN/Ethernet | GbE x 3 [Intel® i210 EtherC-AT x 2] + [Intel® i226 EtherC-AT x 1] [CodeSYS + TwinCAT] |
| USB 3.0 | x 1 |
| USB 2.0 | x 2 |
| RS 232 Serial Port | x 1 |
| RS 485 Serial Port | x 1 |
| Video Output | HDMI x 1 | DP x 1 |
| Wireless | Opsiyonel |
| Bluetooth | Opsiyonel |
| Power Consumption | 40W |
| Mounting Type | Desktop / VESA |
| Supply Voltage | DC 12-36 V |
| Working temperature | -10°C ~ 60°C |
| External Dimensions (mm) | 237 x 153 x 45 |
| Body Material | Aluminum | Body Color: Metallic Gray |
| Certificates | CE | FCC | ROHS | ISO |
| Supported Operating Systems | Windows®10 | Windows®11 | Linux | Operating system sold separately from license. |
