OMNI-2215HTT-ADP-A2-1010
Brand: AAEON [An ASUS Co.]
Categories:
The OMNI-2215HTT-ADP-A2-1010 offers high-performance computing with its 21.5” full HD display and Intel® Core™ i3-1215UE processor.
It provides fast data processing with DDR5 [Max 64GB] RAM support and M.2 2280 M-Key x1 storage.
It offers extensive hardware support with RS 232/422/485 serial ports and GbE x 2 Ethernet connections.
It is suitable for industrial use with its operating temperature range of -25°C ~ 55°C and DC 9-30V power input.
It offers flexible connectivity options with HDMI x1 video output and M.2 3052 B-Key expansion slot.
Features
| Product Code | OMNI-2215HTT-ADP-A2-1010 |
| Screen size | 21.5" TFT LCD |
| Resolution | 1920 x 1080 |
| Screen Format | 16 | 9 |
| Brightness | 250 cd/m² |
| Viewing Angle | 178°(H) / 178°(V) |
| Touch Type | Projective Kapasitif [P-CAP] |
| Backlight Life (Min. Hours) | 50000 |
| Cooling | Without Fan |
| Processor [CPU] | Intel® Core™ i3-1215UE 6 Core 1.20 / 4.40 GHz | BM : 9643 |
| Processor [CPU] Family | Intel® Core™ i3 12. Gen |
| RAM [System Memory] | DDR5 [Max 64 GB] |
| SSD/HDD/mSATA/M.2 | 2.5" SATA3 x1 M.2 2280 M-Key x1 (PCIe x4 for NVMe) |
| LAN/Ethernet | GbE x 2 |
| USB 3.2 | x 3 |
| USB 2.0 | x 1 |
| RS 232/422/485 Serial Port | x 2 |
| Video Output | HDMI x1 |
| Expansion Slot | M.2 3052 B-Key x 1 (Standard: USB 3.2 Gen 2 + SATA, PCIe x2 Optional by BOM) M.2 2230 E-Key x 1 (PCIe, USB 2.0) |
| Mounting Type | VESA / Panel Mount |
| Supply voltage | DC 9-30 V |
| Working temperature | -25°C ~ 55°C |
| External Dimensions (mm) | 21.63” x 14.66” x 2.64” (549.4 x 372.4 x 67) |
| Weight (kg) | 7 |
| Body Material | Aluminum Front Frame + Metal Chassis |
| Certificates | CE/FCC Class A Compatible |
| Supported Operating Systems | Windows®10 | Windows®11 | Linux | Operating system sold separately from license. |
