MIX-H310A2-A12-210FT
Brand: AAEON [An ASUS Co.]
Categories:
MIX-H310A2-A12-210FT offers high performance for industrial applications with the 8th/9th Generation Intel® Core™ LGA1151 socket processor.
It has expandable features and reliable data processing capacity with 65W TDP.
It provides strong hardware support with USB, HDMI, RS-232 connections and PCIe slots.
It is compatible with Windows and Linux operating systems and offers wide operating system support.
It is a suitable solution for industrial automation systems with its various connection points and expandability.
Features
| Product Code | MIX-H310A2-A12-210FT |
| Form Factor | Mini-ITX |
| Card Size (mm) | 170 x 170 |
| Cooling | Fan |
| Processor [CPU] | Intel® Xeon® |Core™ i7 | i5 | i3 | Pentium® | Celeron® |
| Processor [CPU] Family | Konfigüre edilebilir Intel® Xeon® |Core™ i7 | i5 | i3 | Pentium® | Celeron® |
| RAM [System Memory] | [Max 32 GB] |
| SSD/HDD/mSATA/M.2 | M.2 M Key x 1 | SATA3 x 2 |
| LAN/Ethernet | GbE x 2 |
| USB 3.2 | x 4 |
| USB 2.0 | x 2 |
| RS 232 Serial Port | x 1 |
| RS 232/422/485 Serial Port | x 1 |
| Video Output | HDMI x 1 + VGA x 1 + DP x 1 + LVDS x 1 |
| Expansion Slot | PCIe 3.0[x16] x 1 | PCIe 3.0[x16] x 1 |
| Supply Voltage | ATX |
| Working temperature | 0°C ~ 60°C |
| Certificates | CE |
| Supported Operating Systems | Windows®10 | Linux Ubuntu 18.04 | Operating system sold separately from license. |
