MIX-H310A1-A10-4L
Brand: AAEON [An ASUS Co.]
Categories:
MIX-H310A1-A10-4L supports the 8th Generation Intel® Core™ processor family, one of the latest innovations in the Industry.
6 Core graphics engine performance supports machine vision kiosk and graphics-intensive robotics optimized computing applications.
Provides image processing and recognition applications for external IP cameras with 4 Gigabit LAN ports.
It offers home screen functions with 4K HDMI 1.4 and HDCP support.
It offers a high-performance and reliable solution for various industrial applications.
Features
| Product Code | MIX-H310A1-A10-4L |
| Form Factor | Mini-ITX |
| Card Size (mm) | 170 x 170 |
| Cooling | Fan |
| Processor [CPU] | Intel® Xeon® |Core™ i7 | i5 | i3 | Pentium® | Celeron® |
| Processor [CPU] Family | Konfigüre edilebilir Intel® Xeon® |Core™ i7 | i5 | i3 | Pentium® | Celeron® |
| RAM [System Memory] | [Max 16 GB] |
| SSD/HDD/mSATA/M.2 | M.2 M Key x 1 | SATA3 x 2 |
| LAN/Ethernet | GbE x 4 |
| USB 3.0 | x 4 |
| USB 2.0 | x 4 |
| RS 232 Serial Port | x 1 |
| RS 232/422/485 Serial Port | x 1 |
| Video Output | HDMI x 1 + VGA x 1 |
| Expansion Slot | PCIe 3.0 [x16] x 1 | M.2 M Key x 1 | M.2 E Key x 1 |
| Supply Voltage | ATX |
| Working temperature | 0°C ~ 60°C |
| Certificates | CE |
| Supported Operating Systems | Windows®10 | Windows®8 | Windows®7 | Linux Ubuntu 22.04 | Operating system sold separately from license. |
