ITRP-3805-C
Brand: Litemax [An ASUS Co.]
Categories: EN50155 Rail System Panel PC
•37.6" EN50155 Railway Full IP54 Fan Panel PC
• Intel® 6th Skylake mobile processor support
• 37.6 inch LCD, 1920 x 540, 1000 cd/m²
• EN50155 railway certified
• Full IP54 and Fanless design
• Supports 24/36/48/72/96/110 VDC input with M12 connector
• Anti-Shock and vibration
Features
| Product Code | ITRP-3805-C |
| Screen size | 28" TFT LCD |
| Resolution | 1920 x 540 |
| Brightness | 1000 cd/m² |
| Viewing Angle | 178°(H) / 178°(V) |
| Cooling | Without Fan |
| Processor [CPU] | Intel® Celeron® 3955U 2 Core 2.00 GHz | BM : 1580 |
| Processor [CPU] Family | Intel® Celeron® |
| RAM [System Memory] | [Max 16 GB] |
| USB 2.0 | x 2 |
| RS 232 Serial Port | x 1 |
| Audio Output | Dahili Hoparlör |
| Expansion Slot | Full Size Mini PCIe x 1 |
| Supply Voltage | DC 110 V Standart| Opsiyonel DC 24 V| DC 48 V| DC 72 V |
| Working temperature | -25°C ~ 55°C |
| External Dimensions (mm) | 1039.6 x 67.8 x 310.1 |
| Body Material | Aluminum |
| IP Protection Class | Front IP65 |
| Certificates | CE | FCC | EN50155 | LVD |
| Supported Operating Systems | Windows®10 | Windows®8 | Windows®7 | Linux Ubuntu 22.04 | Operating system sold separately from license. |
