ICS-6280A-A10-00
Brand: AAEON [An ASUS Co.]
Categories:
ICS-6280A-A10-00 is designed as an Industrial grade network device and provides secure network connections for the most demanding industrial environments.
It offers high-performance network solutions with its Intel® Atom™ x6425E processor.
With 4 x GbE ports, it provides an ideal solution for network traffic-intensive applications.
It can operate in harsh conditions with its wide temperature range of -40°C ~ 75°C and DC 9-48 V voltage support.
It offers expandable connectivity with Wi-Fi and cellular network support.
Features
| Product Code | ICS-6280A-A10-00 |
| Cooling | Without Fan |
| Processor [CPU] | Intel® Atom™ x6425E 4 Core 2.00 GHz BM : 3830 |
| Processor [CPU] Family | Intel® Atom® |
| RAM [System Memory] | DDR4 |
| SSD/HDD/mSATA/M.2 | 2.5" SATA x 1 |
| LAN/Ethernet | GbE x 4 |
| USB 3.2 | x 2 |
| Video Output | HDMI x 1 + VGA x 1 |
| Expansion Slot | mSATA | SATAIII x 1 | Micro SIM |
| Wireless | Wi-Fi / BT Opsiyonel |
| Mounting Type | Din Rail |
| Supply Voltage | DC 9-48 V Redundant V |
| Working temperature | -40°C ~ 75°C |
| External Dimensions (mm) | 130 x 126 x 72 |
| Body Material | Aluminum |
| Certificates | CE |
