| Product Code |
IB917F-3965(MOQ) |
| Form Factor |
3.5" SubCompact Board
|
| Card Size (mm) |
146 x 101.7
|
| Processor [CPU] |
Intel® Celeron® 3965U 2 Core 2.20 GHz | BM : 1135
|
| Processor [CPU] Family |
Intel® Celeron®
|
| RAM [System Memory] |
[Max 32 GB]
|
| SSD/HDD/mSATA/M.2 |
mSATA x 1 | SATA3 x 2
|
| LAN/Ethernet |
GbE x 2
|
| USB 3.0 |
x 4
|
| RS 232/422/485 Serial Port |
x 1
|
| Digital I/O |
DIx 4 / DOx 4
|
| Video Output |
HDMI x 1 + DP x 1 + eDP x 1 + LVDS x 1
|
| LVDS |
24 bit 1CH x 1
|
| Expansion Slot |
Mini-PCIe [x1] x 1
|
| Supply Voltage |
DC 9-19 V
|
| Certificates |
CE
|
