IB908AF-4300
Brand: IBASE
Categories:
IB908 is a compact SBC supporting 4th Generation Intel® Core™ processor family U-series with BGA1168 (MCP) socket and offers a much lower power design compared to previous generations. IB908 is an ideal platform for demanding applications in space-limited environments such as industrial automation, communications, and POS/Kiosk that require low power, flexible expansion, and superior performance.
Supporting Intel's latest dual-Core single-chip processors (i7-4650U/i5-4300U/i3-4010U), the IB908 includes faster GT3/GT2 graphics for onboard display interfaces such as DVI-I and 24-bit dual-channel LVDS. Two DDR3L-1600 SO-DIMM slots, 16
Like other IBASE single board computers, the IB908 is built for the highest quality and long-term availability and is backed by excellent technical support.
Features
| Product Code | IB908AF-4300 |
| Form Factor | 3.5" SubCompact Board |
| Card Size (mm) | 146 x 101.7 |
| Processor [CPU] | Intel® Core™ i5-4300U 2 Core 1.90 GHz | BM : 2495 |
| Processor [CPU] Family | Intel® Core™ i5 4. Gen |
| RAM [System Memory] | [Max 16 GB] |
| SSD/HDD/mSATA/M.2 | mSATA x 1 | SATA3 x 2 |
| LAN/Ethernet | GbE x 2 |
| RS 232/422/485 Serial Port | x 1 |
| Digital I/O | DIx 4 / DOx 4 |
| Video Output | DVI-I x 1 + LVDS x 1 |
| LVDS | 24 bit 1CH x 1 |
| Expansion Slot | Mini-PCIe [x1] x 2 |
| Supply Voltage | DC 9-19 V |
| Certificates | CE |
