HPC-RPSC-A10-0001
Brand: AAEON [An ASUS Co.]
Categories:
HPC-RPSC-A10-0001 provides powerful solutions for industrial applications with 12th/13th COM HPC Client Size C.
Provides high performance with Intel® Core™ 12th Gen-13th Gen i9 | i7 | i5 | i3 processor support.
DDR5 4800MHz, Dual Channel SODIMM x 2 provides powerful data processing capacity with support for up to 64GB RAM.
It provides wide compatibility with GbE x 2, USB 3.2 x 2, USB 2.0 x 8, USB Type-C x 4 connectors.
It offers system expansion possibilities with PCIe [x16] x 1, PCIe [x4] x 3 expansion slots.
Features
| Product Code | HPC-RPSC-A10-0001 |
| Form Factor | COM HPC Client Size C |
| Card Size (mm) | 160 x 120 |
| Cooling | Optional: Heat Spreader |
| Processor [CPU] | Intel® Xeon® |Core™ i7 | i5 | i3 | Pentium® | Celeron® |
| Processor [CPU] Family | Konfigüre edilebilir Intel® Xeon® |Core™ i7 | i5 | i3 | Pentium® | Celeron® |
| RAM [System Memory] | DDR5 [Max 64 GB] |
| SSD/HDD/mSATA/M.2 | mSATA x 1 | SATA3 x 1 |
| LAN/Ethernet | GbE x 2 |
| USB 3.2 | x 2 |
| USB 2.0 | x 8 |
| USB Type-C | x 4 |
| Digital I/O | GPIO |
| Video Output | eDP x 1 + DDI x 3 |
| Expansion Slot | PCIe [x16] x 1 | PCIe [x4] x 3 | PCIe [x1] x 8 | PCIe [x16] x 1 | PCIe [x4] |
| SMBUS | x 1 |
| Supply Voltage | DC 12 V |
| Working temperature | 0°C ~ 60°C |
| Certificates | CE | FCC |
| Supported Operating Systems | Windows®10 | Windows®11 | Linux | Operating system sold separately from license. |
