GENE-CML5-A10-0012
Brand: AAEON [An ASUS Co.]
Categories:
GENE-CML5-A10-0012 provides support for 10th Generation processors with Intel® Celeron® N series.
It supports up to 64GB DDR4 RAM, suitable for applications with high memory requirements.
Provides flexible expandability with dual Gigabit Ethernet ports and PCIe x4 expansion slot.
It offers VGA and LVDS options as video output.
Compatible with Windows 10 and Linux Ubuntu 20.04, ideal for industrial and AI applications.
Features
| Product Code | GENE-CML5-A10-0012 |
| Form Factor | 3.5" SubCompact Board |
| Cooling | Without Fan |
| Processor [CPU] | Intel® Xeon® |Core™ i7 | i5 | i3 | Pentium® | Celeron® |
| Processor [CPU] Family | Konfigüre edilebilir Intel® Xeon® |Core™ i7 | i5 | i3 | Pentium® | Celeron® |
| RAM [System Memory] | DDR5 x 2 [Max 64 GB] |
| SSD/HDD/mSATA/M.2 | SATA x 3 |
| LAN/Ethernet | GbE x 2 |
| USB 3.2 | x 2 |
| USB 2.0 | x 4 |
| RS 232/422/485 Serial Port | x 2 |
| Video Output | VGA x 1 |
| LVDS | 18/24bit 2CH x 1 |
| Audio Output | Mic-in x 1 + Line-out x 1 |
| Expansion Slot | M.2 2280 M Key x 1 |
| Power Consumption | Intel® i7-10700TE, DDR4 3200Mhz 32 GB x2, 5.64A @ +12V(Typical)Intel® i7-10700TE, DDR4 3200Mhz 32 GB x2, 10.63A @ +12V(Max) |
| Supply Voltage | DC 12 V |
| Working temperature | 0°C ~ 60°C |
| External Dimensions (mm) | 146 x 101.7 |
| Certificates | CE/FCC class A |
| Supported Operating Systems | Windows®10 | Linux Ubuntu 20.04 | Operating system sold separately from license. |
