GENE-BSW5-A12-0002
Brand: AAEON [An ASUS Co.]
Categories:
GENE-BSW5-A12-0002 provides low power consumption with Intel® Celeron® N3160 processor.
It offers a compact design with a 3.5" SubCompact form factor.
It provides wide connectivity options with 2 x GbE Ethernet ports and 8-bit digital I/O support.
It offers flexible connections with USB 3.0 and RS-232/422/485 serial ports.
Compatible with Windows 10 and Linux Ubuntu 22.04, it is a reliable solution for industrial applications.
Features
| Product Code | GENE-BSW5-A12-0002 |
| Form Factor | 3.5" SubCompact Board |
| Card Size (mm) | 101.6 x 146 |
| Cooling | Without Fan |
| Processor [CPU] | Intel® Celeron® N3160 4 Core 1.60 GHz | BM : 1190 |
| Processor [CPU] Family | Intel® Celeron® |
| RAM [System Memory] | [Max 8 GB] |
| SSD/HDD/mSATA/M.2 | mSATA x 1 |
| LAN/Ethernet | GbE x 2 |
| USB 3.0 | x 2 |
| RS 232/422/485 Serial Port | x 2 |
| Digital I/O | DIOx 8 |
| Video Output | VGA x 1 + LVDS x 1 |
| LVDS | 24 bit 1CH x 1 |
| Expansion Slot | Full Size Mini-PCIe |
| Supply Voltage | DC 12 V |
| Certificates | CE |
| Supported Operating Systems | Windows®10 | Windows®8 | Windows®7 | Linux Ubuntu 22.04 | Operating system sold separately from license. |
