| Product Code |
BYTEM-W072-PC |
| Screen size |
7" TFT LCD |
| Resolution |
1024 x 600 |
| Screen Format |
16 | 10 |
| Brightness |
500 cd/m² |
| Contrast |
500 | 1 |
| Viewing Angle |
150°(H) / 150°(V)
|
| Touch Type |
Projective Kapasitif [P-CAP]
|
| Backlight Life (Min. Hours) |
50000
|
| Cooling |
Without Fan
|
| Processor [CPU] |
Intel® Atom® E3825 2 Core 1.33 GHz | BM : 400
|
| Processor [CPU] Family |
Intel® Atom®
|
| RAM [System Memory] |
Standart 2 GB DDR3L [Max 4 GB]
|
| SSD/HDD/mSATA/M.2 |
2.5" SATA x 1 | [Yükseltilebilir]
|
| LAN/Ethernet |
GbE x 1
|
| USB 3.0 |
x 1
|
| USB 2.0 |
x 1
|
| RS 232 Serial Port |
x 1
|
| RS 232/422/485 Serial Port |
x 1
|
| Video Output |
DP x 1
|
| Mounting Type |
VESA 75 | Panel Mount | Stand | Mounting Unit Not Included.
|
| Supply Voltage |
DC 12-24 V
|
| Working temperature |
-10°C ~ 55°C
|
| External Dimensions (mm) |
221.5 x 143.5 x 45.8
|
| Body Material |
Aluminum
|
| IP Protection Class |
Front IP65
|
| Certificates |
CE | FCC
|
| Supported Operating Systems |
Windows®10 | Windows®8 | Windows®7 | Linux Ubuntu 22.04 | Operating system sold separately from license.
|
