BOXER-6710-A2-1011
Brand: AAEON [An ASUS Co.]
Categories: DIN Rail PC
BOXER-6710 is a compact Din Rail Embedded (Embedded) computer. N3350 is powered by Intel Celeron or Pentium N4200 is a rugged and powerful build for industrial applications.
All feature a wide variety of I/O ports for ease of access and maintenance.
Supports Expansion options such as Intel Movidius Myriad
Features
| Product Code | BOXER-6710-A2-1011 |
| Cooling | Fanless |
| Processor [CPU] | Intel® Pentium® N4200 4 Core 1.10 GHz | BM : 2150 |
| Processor [CPU] Family | Intel® Pentium® |
| RAM [System Memory] | [Max 8 GB] |
| SSD/HDD/mSATA/M.2 | mSATA x 1 | 2.5" SATA x 1 |
| LAN/Ethernet | GbE x 2 |
| USB 3.0 | x 4 |
| RS 232 Serial Port | x 3 |
| Video Output | HDMI x 1 + VGA x 1 |
| Audio Output | Mic-in x 1 + Line-out x 1 |
| Expansion Slot | Half Size Mini-PCIe x 6 |
| Mounting Type | Din Rail |
| Supply Voltage | DC 9-19 V |
| Operating temperature | -30°C ~ 60°C |
| External Dimensions (mm) | 44 x 166 x 106 |
| Chassie Material | Aluminum |
| Certificates | CE | FCC |
| Supported Operating Systems | Windows 10 | Windows 8 | Windows 7 | Linux Ubuntu 22.04 | Licence Price is excluded. |
