ACP-1108HTT-A2-1010
Brand: AAEON [An ASUS Co.]
Categories: Industrial Panel PC
10.1" WXGA Multi-Touch Panel PC with NVIDIA® Jetson™ Nano™
Features
- 10.1"WXGA (1280 x 800) Color TFT LCD Screen - 4 GB LPDDR4 - 16 GB eMMC - Projected Capacitive Touch - IP65 Compatible Aluminum Front Frame - VESA 75/Panel Mount Support - DC 12~24V - Windows 11 Support
- 10.1"WXGA (1280 x 800) Color TFT LCD Screen - 4 GB LPDDR4 - 16 GB eMMC - Projected Capacitive Touch - IP65 Compatible Aluminum Front Frame - VESA 75/Panel Mount Support - DC 12~24V - Windows 11 Support
- 10.1"WXGA (1280 x 800) Color TFT LCD Screen - 4 GB LPDDR4 - 16 GB eMMC - Projected Capacitive Touch - IP65 Compatible Aluminum Front Frame - VESA 75/Panel Mount Support - DC 12~24V - Windows 11 Support
- 10.1"WXGA (1280 x 800) Color TFT LCD Screen - 4 GB LPDDR4 - 16 GB eMMC - Projected Capacitive Touch - IP65 Compatible Aluminum Front Frame - VESA 75/Panel Mount Support - DC 12~24V - Windows 11 Support
- 10.1"WXGA (1280 x 800) Color TFT LCD Screen - 4 GB LPDDR4 - 16 GB eMMC - Projected Capacitive Touch - IP65 Compatible Aluminum Front Frame - VESA 75/Panel Mount Support - DC 12~24V - Windows 11 Support
- 10.1"WXGA (1280 x 800) Color TFT LCD Screen - 4 GB LPDDR4 - 16 GB eMMC - Projected Capacitive Touch - IP65 Compatible Aluminum Front Frame - VESA 75/Panel Mount Support - DC 12~24V - Windows 11 Support
- 10.1"WXGA (1280 x 800) Color TFT LCD Screen - 4 GB LPDDR4 - 16 GB eMMC - Projected Capacitive Touch - IP65 Compatible Aluminum Front Frame - VESA 75/Panel Mount Support - DC 12~24V - Windows 11 Support
- 10.1"WXGA (1280 x 800) Color TFT LCD Screen - 4 GB LPDDR4 - 16 GB eMMC - Projected Capacitive Touch - IP65 Compatible Aluminum Front Frame - VESA 75/Panel Mount Support - DC 12~24V - Windows 11 Support
Features
| Product Code | ACP-1108HTT-A2-1010 |
| Screen size | 10.1" TFT LCD |
| Resolution | 1280 x 800 |
| Screen Format | 16 | 10 |
| Brightness | 300 cd/m² |
| Contrast | 1000 | 1 |
| Viewing Angle | 170°(H ) / 170°(V) |
| Touch Type | Projected Capasitif [P-CAP] |
| Backlight Life (Min. Hours) | 25000 |
| Cooling | Fanless |
| Processor [CPU] | RockChip™ RK3568 + Quad Core Cortex® A55 2.00 GHz |
| Processor [CPU] Family | RockChip™ |
| RAM [System Memory] | 4 GB Onboard |
| SSD/HDD/mSATA/M.2 | 16 GB eMMC |
| LAN/Ethernet | GbE x 2 |
| USB 3.2 | x 2 |
| USB 2.0 | x 2 |
| RS 232 Serial Port | x 1 |
| RS 232/422/485 Serial Port | x 1 |
| Video Output | HDMI x 1 |
| Expansion Slot | Full Size Mini-PCIe x 1 |
| Mounting Type | VESA 75 | Panel Mount | Mounting Unit Not Included. |
| Supply Voltage | DC 12-24 V |
| Operating temperature | -5°C ~ 50°C |
| External Dimensions (mm) | 267 x 185 x 40 |
| Chassie Material | Aluminum |
| IP Protection Class | Front IP65 |
| Certificates | CE | FCC |
| Supported Operating Systems | Android 12.x |
